CONFAST®

1/4" x 3" Nylon Nail-It Mushroom Head, 100/Box

(No reviews yet) Write a Review
SKU:
NNM143
UPC:
820274001097
Availability:
Contact us for information, see page for alternatives.
$25.00

OUT OF STOCK

Description

Products Features
  • LIGHT​ ​DUTY:  Ideal ​for ​small ​anchoring​ ​jobs
  • ANCHOR ​BODY ​IS ​MADE ​FROM​ ​A ​NYLON MATERIAL:  Anchor ​body ​will ​not ​rust and ​this provides ​easier maintenance
  • INSTALL ​IN ​A ​VARIETY ​OF ​BASE ​MATERIALS:  Versatile ​makes ​fastening ​a ​​ ​fast ​and ​simple application ​process
  • 3 ​HEAD ​STYLES:  Mushroom, ​Round ​or ​Flat ​Countersunk ​meets most ​application ​requirements; ​provides ​choice
  • SIMPLE ​TO ​USE:  Drill ​a ​hole, ​insert ​anchor ​then ​drive ​the ​hammer
Products specifications
Bit Size 1/4"
Box Qty 100
Minimum Embedment 3/4"
Head Type Mushroom
Minimum Edge Distance 1-1/4"
Maximum Fixture Thickness 2-1/4"
Minimum Fixture Hole Diameter (In Place) 5/16"
Minimum Fixture Hole Diameter (Hole Spotted) 5/16"
Brand Name CONFAST®
Minimum Spacing 2-1/2"
2000 PSI Concrete - Pull-Out (lbs.) * 165
2000 PSI Concrete - Shear (lbs.) * 240
Length Measurement Underneath head
Diameter 1/4"
Length 3"
Material Nylon Body -Carbon Steel Zinc Plated Nail
Environment Dry
Type Male
* Values shown are average ultimate values and are offered only as a guide and are not guaranteed. A safety factor of 4:1 or 25% is generally accepted as a safe working load
Application Photos
1/4" x 3" Mushroom Head Nylon Nail it - block - sign on 2x4
View AllClose

Additional Information

Bit Size:
1/4"
Minimum Embedment:
3/4"
Type:
Male
Material:
Nylon Body -Carbon Steel Zinc Plated Nail
Environment:
Dry
2000 PSI Concrete - Pull-Out (lbs.) *:
165
2000 PSI Concrete - Shear (lbs.) *:
240
Diameter:
1/4"
Length:
3"
Box Qty:
100
Minimum Spacing:
2-1/2"
Minimum Edge Distance:
1-1/4"
Maximum Fixture Thickness:
2-1/4"
Minimum Fixture Hole Diameter (In Place):
5/16"
Minimum Fixture Hole Diameter (Hole Spotted):
5/16"
Head Type:
Mushroom
Length Measurement:
Underneath head
Brand Name:
CONFAST
View AllClose
